Description

The UNI-T UT601 Digital Inductance Capacitance LCR Meter is a versatile testing instrument designed for measuring resistance and capacitance in electronic circuits and components. It also provides diode, transistor, and continuity testing functions, making it useful for electronics repair, laboratories, workshops, and educational applications.

Its manual ranging system and large LCD display provide convenient operation and clear readings. The compact design makes it easy to handle and suitable for everyday electronic testing.

Key Features

• Measures resistance and capacitance
• Diode testing function
• Transistor testing function
• Continuity test with buzzer
• Manual ranging
• Low battery indication
• Clear 3½-digit LCD display
• Compact and portable design
• Suitable for electronics repair, laboratories, and educational use

Package Includes

• 1 × UNI-T UT601 LCR Meter
• 1 × Test Clip Set
• 1 × User Manual

Note: Battery is not included in the package.

Specifications

• Model: UNI-T UT601
• Display: 3½-digit LCD, 61 × 32 mm
• Display Count: 2000
• Resistance Range: 20Ω / 200Ω / 2kΩ / 20kΩ / 200kΩ / 2MΩ / 20MΩ / 200MΩ / 2000MΩ
• Resistance Accuracy: ±(0.8% + 1)
• Capacitance Range: 200pF / 2nF / 20nF / 200nF / 2µF / 20µF / 200µF / 2mF / 20mF
• Capacitance Accuracy: ±(0.5% + 10)
• Sampling Rate: 2–3 readings/second
• Functions: Resistance, capacitance, diode, transistor, and continuity testing
• Range Selection: Manual
• Low Battery Indicator: Yes
• Power: 9V battery (6F22)
• Product Color: Red and Grey
• Dimensions: 172 × 83 × 38 mm
• Weight: Approx. 310–312 g
