Description
The JST XH 2.54mm 5-Pin Dual Female Connector with 350mm Wire is a compact wire-to-board connector cable designed for making neat and reliable connections between compatible electronic components and PCBs.
It features 5 pins with approximately 2.54mm pitch and female connectors on both ends. The 350mm cable length provides enough flexibility for connecting components that are positioned apart, while the plug-and-connect design makes installation simple without requiring soldering.
The JST XH-style connector is commonly used for PCB and power connections, battery wiring, electronic modules, and various DIY projects. Its compact construction makes it suitable for applications where space and organized wiring are important.
The connector specifications provided include ratings for current, voltage, insulation resistance, contact resistance, and dielectric withstand voltage. For applications requiring the higher ratings mentioned in the general XH-series description, verify the exact connector and wire variant against the manufacturer’s datasheet.
Specifications
| Specification | Details |
|---|---|
| Connector Type | JST XH |
| Connector Configuration | Dual Female |
| Number of Pins | 5 |
| Pin Pitch | Approx. 2.54mm |
| Wire Length | 350mm |
| Wire Type | AWG #24–#32 |
| Insulation O.D. | 1.00mm Max. |
| Current Rating | 1A AC/DC |
| Voltage Rating | 125V AC/DC |
| Temperature Range | −25°C to +85°C |
| Insulation Resistance | 100MΩ Min. |
| Withstanding Voltage | 500V AC/minute |
| Initial Contact Resistance | 10mΩ Max. |
| Contact Resistance After Environmental Tests | 20mΩ Max. |
| Applicable PCB Thickness | 1.6mm |
| Connector Style | Wire-to-Board |
| Series Pitch | 2.54mm |
Features
- 5-pin JST XH-style connector
- Female connector on both ends
- Approx. 2.54mm pin pitch
- 350mm wire length
- Compact and easy-to-connect design
- Suitable for compatible PCB headers
- Flexible wiring for convenient installation
- Useful for power and signal connections
Applications
- RC and Li-Po battery connections
- Battery balance charging
- PCB and module connections
- Electronic development projects
- Suitable PC and laboratory equipment connections
- DIY electronics and hobby projects
- Wire-to-board connections
