Description
DC 36–48V 350W Brushless Motor Controller
This 36–48V 350W Brushless Motor Controller is designed for electric bicycles, e-bikes, and electric scooters using compatible brushless DC (BLDC) hub motors. Its compact and waterproof design makes it suitable for outdoor applications while providing smooth and reliable motor control.
The controller supports three-wire throttle systems and is compatible with brushless motors that use the required 3-phase motor wires and 5 Hall sensor wires. It features 12 MOS tubes for efficient switching and natural heat dissipation for dependable operation.
The controller includes connections for the main power supply, electric lock, throttle, and motor phase wires. Additional functions such as three-speed control, anti-theft, electronic braking system (EBS), and cruise control are also supported when properly connected.
Key Features
- Designed for electric bicycles, e-bikes, and electric scooters
- Compatible with suitable brushless DC hub motors
- Supports 36–48V battery systems
- Rated power of 350W
- Supports three-wire throttle systems
- 12 MOS tubes for reliable motor control
- Three-speed control function
- Anti-theft function
- Electronic braking system (EBS)
- Cruise control support
- Natural cooling for heat dissipation
- Compact and easy-to-install design
- IP55 protection rating
- Suitable for outdoor applications
Compatibility
This controller is intended for compatible brushless DC motors using 3 phase cables and 5 Hall sensor cables. Motor and Hall wiring compatibility should be confirmed before installation.
Installation / Operation
- Connect the power, motor, throttle, and electric-lock cables.
- Initially leave the Hall sensor wires disconnected and connect the adaptive-learning wires.
- Turn on the electric lock and slowly operate the throttle.
- Once the motor operates correctly, connect the Hall sensor wires.
- If the motor rotates in the wrong direction, disconnect the adaptive-learning wire and check the motor operation again before connecting the Hall wires.
Package Includes
- 1 × 36–48V 350W Brushless Motor Controller
Important Note
Please verify the motor voltage, power rating, phase wiring, Hall sensor wiring, and throttle compatibility before installation. Incorrect wiring may cause the controller or motor to malfunction.
Specification
| Specification | Details |
|---|---|
| Product Type | Brushless Motor Controller |
| Rated Voltage | 36–48V DC |
| Rated Power | 350W |
| Rated Current | 7A |
| Motor Type | Brushless DC (BLDC) |
| Phase Angle | 60° / 120° |
| Throttle Voltage | 1–4.2V |
| Brake Level | Low / High |
| Cooling | Natural Cooling |
| Protection Grade | IP55 |
| Operating Temperature | -20°C to 50°C |
| Controller Size | Approx. 103 × 70 × 35 mm |
| Motor Connection | 3 Phase + 5 Hall Sensor Wires |
| Functions | Three-Speed, Anti-Theft, EBS, Cruise |
| Condition | Brand New |
