Description
The 500mAh 3.7V 1S Rechargeable LiPo Battery is a compact and lightweight lithium-polymer battery designed for RC mini drones, mini quadcopters, multicopters, and small electronic projects. With a 3.7V nominal voltage and 500mAh capacity, it provides a convenient rechargeable power source for portable and space-conscious applications.
This 1S LiPo battery has a lightweight design weighing approximately 10g. Its compact dimensions make it suitable for RC models, DIY electronics, robotics, and compatible development-board projects such as ESP8266, ESP32, and ESP32-CAM, provided the device’s voltage and current requirements are properly matched.
Key Features
- Battery Type: Lithium Polymer (LiPo)
- Configuration: 1S
- Nominal Voltage: 3.7V
- Capacity: 500mAh
- Maximum Charge Voltage: 4.25V
- Weight: 10g
- Dimensions with PCM: 32.5 × 30 × 5mm
- Compact and lightweight rechargeable design
- Suitable for RC mini drones and quadcopters
- Useful for small electronics and DIY projects
- Designed for compatible 3.7V 1S applications
Specifications
| Specification | Details |
|---|---|
| Battery Type | Lithium Polymer / LiPo |
| Model | 503030 |
| Configuration | 1S |
| Nominal Voltage | 3.7V |
| Capacity | 500mAh |
| Maximum Charge Voltage | 4.25V |
| General Charge Current | 0.2C / Adjustable |
| Fast Charge Current | 1C / Adjustable |
| General Discharge Current | 0.2C / Adjustable |
| Maximum Continuous Discharge | 1C / Adjustable |
| Peak Discharge Current | 2C / Adjustable |
| Cycle Life | 500+ cycles at 0.2C, 80% DOD |
| Dimensions with PCM | 32.5 × 30 × 5mm |
| Weight | 10g |
Applications
The 500mAh 3.7V 1S LiPo battery is suitable for:
- RC mini drones
- Mini quadcopters
- Multicopters
- Small remote-controlled devices
- ESP8266 projects
- ESP32 development projects
- ESP32-CAM projects
- Small robotics projects
- DIY electronics
- Portable electronic devices
- Compact battery-powered equipment
- Other compatible 1S 3.7V LiPo applications
