Creality 3D Printer Mechanical Endstop Limit Switch Module with Cable

The Creality Mechanical Endstop Limit Switch Module is designed to detect the end or home position of the X, Y, or Z axis on compatible Creality 3D printers. When the mechanical switch is triggered, it sends a signal to the printer’s control board, allowing the printer to stop movement and establish the correct home position.

This module uses a mechanical microswitch with a physical lever, providing a simple and reliable method of position detection. It features a standard 3-pin connection for power, ground, and signal, making it suitable for many Creality printer configurations.

Its compact construction allows it to fit into the existing mounting locations of compatible printers with minimal modification. It can be used as a replacement when an existing endstop becomes worn, damaged, or fails to trigger correctly.

Keeping a spare endstop module can also be useful for troubleshooting homing errors, incorrect axis positioning, or failed limit detection.

Key Features

• Mechanical Endstop: Uses a physical microswitch for reliable axis position detection.
• 3-Pin Connection: Standard connector with power, ground, and signal connections.
• Reliable Position Detection: Helps the printer identify the home and limit position of an axis.
• Compact Design: Suitable for installation in compatible Creality printer mounting locations.
• Easy Replacement: Designed as a replacement for worn or damaged endstop modules.
• Wide Compatibility: Suitable for selected Creality Ender and CR-series 3D printers.
• Suitable for X/Y/Z Axes: Can be used wherever a compatible mechanical endstop is required.

Specifications

Package Includes

• 1 × Mechanical Endstop Limit Switch Board
• 1 × Connecting Wire
