Description
The Standard 30A BLDC ESC Electronic Speed Controller is designed to provide smooth and responsive speed control for brushless DC motors used in quadcopters, multirotors and RC aircraft. It can handle motors drawing up to 30A continuously, with a higher current capability for short periods.
The ESC supports 2–3S LiPo batteries and includes an onboard BEC for powering compatible flight controllers and other electronics. Its automatic battery-cell detection and low-voltage protection help provide safer and more reliable operation during flight.
It is well suited for A2212 brushless motors in various KV ratings, provided the motor’s current requirement remains within the ESC’s rated limits.
Features
- 30A continuous current rating
- Up to 40A for less than 10 seconds
- Built-in BEC for powering onboard electronics
- 2–3S LiPo battery support
- 4–10 cell Ni-MH/Ni-Cd support
- Automatic battery cell detection
- Low-voltage battery protection
- Motor braking can be switched on or off
- Suitable for brushless DC motors
- Compact and lightweight design
- Recommended for A2212 brushless motors
Specification
- Model: Standard 30A BLDC ESC
- Type: Brushless Electronic Speed Controller
- Continuous Current: 30A
- Maximum Current: 40A for less than 10 seconds
- BEC Output: 5V regulated
- BEC Current: Up to 3A
- LiPo Battery: 2–3 cells
- Ni-MH/Ni-Cd Battery: 4–10 cells
- Low-Voltage Slowdown: 3.0V per LiPo cell
- LiPo Cut-Off: 2.9V per cell
- Brake: On/Off
- Color: Yellow
- Dimensions: 45 × 24 × 9mm
- Weight: 23g
Applications
- Quadcopter and multirotor builds
- RC airplanes
- Brushless motor projects
- A2212 930KV, 1000KV, 1400KV and 2450KV motor setups
Package Includes
- 1 × Standard 30A BLDC ESC Electronic Speed Controller
