Description
The 24V 3A 75W Switching Mode Power Supply (SMPS) is a compact and reliable power solution for electronic devices and 24V DC applications. It converts 110V–220V AC input into a regulated 24V DC output, providing up to 3A of current and 75W of power.
This 24V DC power supply is suitable for powering LED strips, RGB LED lighting, CCTV equipment, 3D printers, SMD lights, advertising displays, and other compatible 24V devices. Its switching-mode design provides efficient power conversion while the built-in overload and short-circuit protection helps protect the power supply and connected equipment.
The unit uses high-temperature-resistant copper enameled wire and a double-winding U-shaped iron core for reliable performance. Its compact 160 × 98 × 42mm design makes it convenient for installation in electronics projects, lighting systems, control panels, and other applications where space is limited.
Key Features
- 24V DC output with up to 3A current
- 75W maximum output power
- 110V–220V AC input voltage
- Switching-mode design for efficient power conversion
- Overload protection
- Short-circuit protection
- Automatic recovery after protection
- High-temperature-resistant copper enameled wire
- Double-winding U-shaped iron core
- Good insulation and electrical strength
- Compact size for easy installation
- Suitable for LED lighting and electronics applications
- CE, RoHS and FCC certification
Specifications
| Specification | Details |
|---|---|
| Product Type | Switching Mode Power Supply (SMPS) |
| Input Voltage | 110V–220V AC |
| Output Voltage | 24V DC |
| Output Current | 3A |
| Output Power | 75W |
| Protection | Overload & Short Circuit |
| Automatic Recovery | Yes |
| Working Temperature | -20°C to +60°C |
| Working Humidity | 20%–90% RH |
| Dimensions | 160 × 98 × 42mm |
| Certifications | CE, RoHS, FCC |
| SKU | CNC-187 |
Applications
The 24V 3A 75W SMPS power supply can be used for a variety of 24V DC applications, including:
- LED strip lighting
- RGB LED strips
- SMD lighting
- CCTV cameras and security systems
- 3D printers
- Street and decorative lighting
- Lawn lamps
- Advertising displays and signs
- DIY electronics projects
- Other compatible 24V DC equipment
