Description
The YIHUA YH-605D DC Power Supply is a reliable adjustable laboratory power supply designed for electronics repair, testing, servicing, and research applications. Its compact all-metal construction provides durability while the regulated output allows precise control of voltage and current for different electronic devices and circuits.
The unit features clear dual LED digital displays, allowing you to monitor output voltage and current during operation. It supports both constant voltage (CV) and constant current (CC) operating modes, giving you greater control when powering and testing electronic circuits.
For added safety, the YH-605D includes short-circuit, overload, and overcurrent protection with a self-recovery protection circuit. A built-in cooling fan and thermal fan switch help maintain reliable operation during extended use.
With continuously adjustable output and stable regulation, the YIHUA YH-605D is suitable for electronics and computer servicing, automotive applications, educational institutions, research laboratories, and general bench testing.
Specifications
| Specification | Details |
|---|---|
| Brand | YIHUA |
| Model | YH-605D |
| Type | Adjustable DC Laboratory Power Supply |
| Input Voltage | AC 220–240V |
| Frequency | 50/60Hz |
| Output Voltage | 0–60V* |
| Output Current | 0–5A |
| Operating Modes | Constant Voltage (CV) / Constant Current (CC) |
| Voltage Stability | ≤0.01% + 2mV |
| Load Stability | ≤0.01% + 2mV |
| Current Stability | 0.1% + 3mA |
| Current Load Stability | 0.2% + 3mA |
| Recovery Time | ≤100µs |
| Voltage Ripple & Noise | ≤1mV RMS |
| Current Ripple & Noise | ≤2mA RMS |
| Temperature Coefficient | ≤200 PPM/°C |
| Working Temperature | -10°C to 40°C |
| Working Humidity | <90% RH |
| Storage Temperature | -10°C to 40°C |
| Storage Humidity | <80% RH |
| Display | Dual LED Digital Display |
| Protection | Short Circuit, Overload & Overcurrent |
| Cooling | Built-in Fan with Thermal Switch |
| Construction | All-Metal |
| Product Weight | 4.6kg |
| Dimensions | 13 × 25.5 × 15cm |
