Description
The 12V High Pressure Booster Pump is a compact diaphragm pump designed for applications requiring high water pressure and reliable fluid movement. It uses a 775 motor with a cooling fan for improved heat management during operation.
Operating from a 9–14V DC supply, the pump provides a flow rate of up to 2.6L/min, a maximum head of 30 meters, and pressure up to 0.45MPa. Its compact design makes it suitable for various portable water pumping and pressurization projects.
Features
- High-pressure 12V diaphragm booster pump
- 775 DC motor
- Built-in cooling fan
- 28W power rating
- Operating voltage range of 9–14V DC
- Maximum pressure of 0.45MPa
- Maximum head of 30 meters
- Flow rate up to 2.6L/min
- Suction capability up to 1.5 meters
- Suitable for portable and DIY water pumping systems
- Compact design for easy installation
Specification
- Pump Type: Diaphragm Booster Pump
- Motor Type: 775 DC Motor
- Rated Voltage: 12V DC
- Operating Voltage: 9–14V DC
- Current: 2.1A
- Power: 28W
- Suction Stroke: 1.5 meters
- Maximum Head: 30 meters
- Flow Rate: 2.6L/min
- Maximum Pressure: 0.45MPa
- Cooling: Built-in Cooling Fan
Applications
- Water pressure boosting
- Portable water pumping systems
- DIY water circulation projects
- Fluid transfer applications
- Spraying and pressurization systems
- Custom 12V pumping projects
