Description
The JST XH 2.54mm 5-Pin Dual Female to Female Connector with 220mm Wire is a small, practical cable assembly designed to make connections between compatible electronic components quick and convenient. It uses a 5-pin configuration with an approximately 2.54mm pitch, making it suitable for matching JST XH-style headers.
Both ends feature female connectors, allowing the cable to be used for extending or connecting compatible components without having to make individual wire connections. The 220mm wire length provides flexibility while helping keep electronic wiring organized.
This connector is commonly useful for PCB and module connections, control boards, RC batteries, Li-Po battery balance charging, power connections, and DIY electronics projects.
For this specific cable, the supplied product specifications list a 1A AC/DC current rating and 125V AC/DC voltage rating. The general JST XH series information may specify higher ratings for other variants, so the product-specific ratings should be used when selecting this cable.
Specifications
| Specification | Details |
|---|---|
| Connector Type | JST XH |
| Connector Configuration | Dual Female to Female |
| Number of Pins | 5 Pins |
| Pin Pitch | Approx. 2.54mm |
| Wire Length | 220mm |
| Wire Type | AWG #24–#32 |
| Insulation O.D. | 1.00mm Max. |
| Current Rating | 1A AC/DC |
| Voltage Rating | 125V AC/DC |
| Temperature Range | −25°C to +85°C |
| Insulation Resistance | 100MΩ Min. |
| Withstanding Voltage | 500V AC/minute |
| Initial Contact Resistance | 10mΩ Max. |
| Contact Resistance After Environmental Tests | 20mΩ Max. |
| Applicable PCB Thickness | 1.6mm |
| Connector Style | Crimp-Type, Wire-to-Board |
| Compliance | RoHS |
Features
- 5-pin JST XH-style connector
- Female connectors on both ends
- Standard 2.54mm pitch
- 220mm wire length
- Compact and space-saving design
- Easy plug-and-connect installation
- Flexible wiring for convenient connections
- Reliable crimp-style construction
- Suitable for compatible PCB headers and modules
Applications
- PCB and electronic module connections
- Control boards
- RC battery connections
- Li-Po battery balance charging
- Power and signal wiring
- Electronic equipment
- DIY electronics and prototyping
- Hobby and embedded projects
