Description
The JST XH 2.54mm 6-Pin Dual Female to Female Connector with 220mm Wire is a compact crimp-style cable designed to provide a simple and reliable way to connect compatible electronic components. Its standard 2.54mm pitch is commonly used with PCBs, electronic modules, and various hobby electronics.
With 6 pins and female connectors on both ends, this cable can be used to extend or connect compatible headers without requiring additional soldering. The 220mm wire length provides useful flexibility while helping keep connections neat and organized.
The connector is well suited for applications such as PCB connections, electronic control boards, RC and Li-Po battery wiring, balance charging setups, and DIY electronics projects.
The general JST XH series information lists higher electrical ratings, but the specifications supplied for this particular product state a 1A AC/DC current rating and 125V AC/DC voltage rating. These product-specific ratings should be used when selecting this cable for an application.
Specifications
| Specification | Details |
|---|---|
| Connector Type | JST XH |
| Connector Configuration | Dual Female to Female |
| Number of Pins | 6 Pins |
| Pin Pitch | Approx. 2.54mm |
| Wire Length | 220mm |
| Wire Type | AWG #24–#32 |
| Insulation O.D. | 1.00mm Max. |
| Current Rating | 1A AC/DC |
| Voltage Rating | 125V AC/DC |
| Temperature Range | −25°C to +85°C |
| Insulation Resistance | 100MΩ Min. |
| Withstanding Voltage | 500V AC/minute |
| Initial Contact Resistance | 10mΩ Max. |
| Contact Resistance After Environmental Tests | 20mΩ Max. |
| Applicable PCB Thickness | 1.6mm |
| Connector Style | Crimp-Type, Wire-to-Board |
| Compliance | RoHS |
Features
- 6-pin JST XH-style connector
- Female-to-female connector configuration
- Standard 2.54mm pitch
- 220mm wire length
- Compact and lightweight design
- Easy plug-and-connect installation
- Reliable crimp-style connection
- Suitable for compatible PCB headers and modules
- RoHS-compliant series design
Applications
- PCB and electronic module connections
- Control boards
- RC battery wiring
- Li-Po battery balance charging
- Power connections
- Electronic equipment
- DIY electronics projects
- Prototyping and hobby circuits
